ACCESSORIES

The EMEC product range includes a wide assortment of reliable, quality accessories for complete and efficient dosing systems in every single component.

Catalogue
GRADUATED CHEMICAL TANKS |

PE tanks for chemical mixing and dosing system.

MIXERS |
  • Agitator suitable for small containers (100 L to 500 L).
  • The lubrication-free worm gear box is coupled with the support flange for attachment to the tank.
  • The shaft is made of PVC-coated stainless steel.
  • An elastic FP seal fitted between the support flange and the PVC casing of the mixer shaft protects the gear box and motor from chemical vapours.
MULTIFUNCTION VALVES |

Multifunction valves for: pressure, safety, anti-syphon, bleed.
Delivery and junction fittings adaptable to different hose diameters.

FLOW SENSORS |
  • PVDF body.
  • N.C. contact.
  • Adjustable sensitivity.
  • Viton® or EPDM O-ring.
  • Max 45°C.
  • Activity LED.
INJECTION LANCES |
  • Reduces chemical deposits and crystalline formations at the injection point.
  • PVDF or PP or AISI 316 body
OFF-LINE PROBE HOLDERS |

SAN transparent or black body.
Can have one or two additional holes (1/2” or 3/4”) upon request.

OFF-LINE PROBE HOLDERS FOR AMPER. CELLS |
  • Off-line probe holders for closed amperometric cells. With flow level control, proximity switch and capacity stabilizer (0.4 to 3 bar).
  • PMMA body and PVDF fittings.
  • LED light strips upon request.
PIPELINE MANIFOLD |

Hydraulic part includes:

  • motorized purge valve
  • water inlet tap
  • water outlet tap
  • check valve
  • flow sensor
  • 3 injection points
  • cross connection for probe conductivity and pH (Redox upon request).

Panel and probes not included.

FILTERS |
  • Water filters for 6×8 hose fittings.
  • Fast installation.
  • Bracket for wall mounting.
  • Transparent SAN housing.
SAFETY BUNDS |

Designed as safety or containment bunds for “CNT” series containers.
Made of polyethylene with built-in upper reinforcement edging.

MANUAL MIXERS |
  • Mixer suitable for tank sizes: 50, 120, 250, 500 l.
  • PVC shaft.
  • 2-blade impeller.
  • Impeller diameter 90 mm.
PULSE DAMPENERS |
  • Pulse dampener without membrane.
  • Available with PP o PVDF lining.
SUCTION LANCES |
  • Level switch (LASP4 with double level probes available).
  • Foot valve and filter.
  • Adjustable height.
  • 1 1/2” pipe fitting.
  • Side outlet with 1/2″ through-valve.
  • PVC or PVDF body.
  • Up to 2 suction outlets available.
IN LINE PROBE HOLDERS |
  • Easy assembly.
  • “T” connection PN 16 Ø40 or Ø63 (PEL-E and PEL-IND).
  • In PVDF for saddle connection (PELC).
IMMERSION PROBE HOLDERS |
  • Immersion electrode holder for pH / Redox probes Ø 12, Eolum, conductivity, inductive conductivity, turbidity and temperature.
  • SN6 version available (PG13.5).
MANIFOLD WITH FLOW SENSOR |

PMMA manifold (except for MAPLTR and MAPLTRE in PVC). PVC version on request without price variation.

PIPE CORROSION CONTROL |

Pipe corrosion control system.

  • PVC body.
  • Pipes: DN40 – PN16.
  • 4 sample holders.
  • Sample holder removable without any tools.
  • Overall dimensions: 600 mm x 900 mm.
  • Inlet / outlet isolation valves.
  • Flow meter.
  • Y-Strainer (optional).
  • Drain valve.
  • Temperature: max 40°C ( 104°F).
STATIC MIXERS |
  • Excellent static mixing with low pressure drop.
  • No moving parts.
  • PVC pipe.
  • Structured filling with PP mixing elements.
  • Minimum pressure drop: 0.2 bar at 5 m3/h.
  • Optimum operation with wide flow rate variations.
  • 1/2” injection valve – 4×6 / 0.3 bar.
