   PROBES

EMEC probes and sensors are the ideal complement to our control and dosing systems. Thanks to the careful design and constant evaluation work by our engineers, EMEC probes guarantee the utmost accuracy, reliability and efficiency in all types of measurements required for chemical dosing and water treatment.

ECL
SCL
EOLUM
ETORB2
ETRC2
EPH
ERH
ECDH

ECDC
ECDI
EICD
ECDIND
ETE
SLL
ECORR
SLV

Catalogue

CELLE AMPEROMETRICHE

SCL |

Closed amperometric cells for the chlorine and chlorine dioxide measurement. They guarantee stable, precise measurements even at low chlorine concentrations. Negligible dependence of chlorine dioxide on the pH value. Closed amperometric cells consist of a special membrane and an electrode placed inside and immersed in an electrolyte (except models SCL 17 and SCL 18).

ECL |

Open amperometric cells for measuring chlorine (hypochlorous acid) with an acrylic body. Some models can accommodate up to three additional probes (temperature, pH and Redox). Constant flow 40 l/min. A pressure stabiliser is available for applications in locations subject to pressure fluctuations. They guarantee stable, precise measurements even at low chlorine concentrations. Continuous measuring range. Flow control and constant flow via proximity sensor (ECL6; ECL6/E; ECL7; ECL12; ECL12/E).

Manual Datasheet

CONDUCTIVITY PROBES

ECDIND |

Inductive conductivity probes with PEEK body. Stable reading. Cable/connector 4 m.

ECDI |

Conductivity probes with stainless steel electrodes (AISI 316) and PVDF body. Cable/connector 5 m (also available 10 m / 15 m / 20 m).

ECDH |

High linearity conductivity probes with Epoxy body and platinum electrodes. Cable/connector 4.5 m.

ECDC |

Conductivity probes with graphite electrodes (K1/ K10) and PVDF body. Cable/connector 5 m (also available 10 m / 15 m / 20 m).

EICD |

Stainless steel conductivity probes. Conductivity probe with AISI 316 stainless steel electrodes and body. Cable/connector 5 m (also available 10 m / 15 m / 20 m).

DISSOLVED OXYGEN PROBE

EOLUM |

Dissolved oxygen probe. Probe for measuring dissolved oxygen using a fluorescent membrane: analysis system based on the fluorescence principle.

PTSA PROBE

ETRC2 |

PTSA probe. PTSA fluorescent tracer probe with PVC body and LED signal source.

PH PROBE

EPH |

PH probes. Probes for pH measurement in water, with Epoxy or glass body. Cable available in various lengths.

REDOX PROBES

ERH |

REDOX probes. Probes for measuring the Redox potential in water, with Epoxy or glass body. Cable available in various lengths.

TEMPERATURE PROBES

ETE |

Temperature measuring probes with PVDF body.

CORROSION RATE PROBES

ECORR |

Probe for measuring corrosion up to a corrosion rate of 0.001 MPY. Generic and material-specific corrosion. Anti-electromagnetic interference (anti-EMI) with stainless steel sensor body. RS-485 connection. Three O-rings on the sensor body allow control of the installation depth.

TURBIDITY PROBE

ETORB2 |

Turbidity probe. Probe for turbidity measurement according to the 90° scattered light measuring principle. Sensor surface with inclined plane, factory calibration. Also available ETORB2-IM: immersion probe.

LASER LEVEL SENSOR

SLL |

Laser level sensor for liquid level measurement. Also suitable for aggressive fluids because they are not in contact with the liquid. Measuring range 0.2-10 m (on white paper 200 x 200 mm, 90% reflection). RS485 digital or 4-20 mA analogue output.

VISUAL LEVEL DETECTION SYSTEM

SLV |

Visual level indicator for CNT PD containers.
