Disinfection systems

LOTUS DISINFECTION SYSTEMS

SAFE DISINFECTION

LOTUS chlorine dioxide generators are the most effective solution for water disinfection in a variety of applications and in particular for the prevention of legionellosis in domestic hot and cold water systems.

The bacterium that causes legionellosis, Legionella, is able to adapt even to conditions that would be fatal to other organisms. Thanks to its high Redox potential, chlorine dioxide exerts a more powerful disinfectant action than other biocides against Legionella and all kinds of germs and contaminants such as viruses, bacteria, fungi and algae. The oxidation potential is higher than that of chlorine, for example, so fewer chemicals can be used. Potentially dangerous disinfection by-products are absent and it is proven to penetrate and degrade the Legionella habitat. The action of the chlorine dioxide is independent of the pH value of the water, is not aggressive towards pipes and has a longer-lasting and wider-ranging effect from the injection point.

Scientific tests have shown the effectiveness of the disinfectant action, with almost 100% killing of Legionella in just 30 minutes and elimination of the proliferation habitat. Safety is ensured by the atmospheric pressure production process, in which chlorine dioxide is never treated in its gaseous form but is produced by reacting two liquid precursors in a reaction chamber in only the amount needed at the time.

Particle element
Particle element

   CHLORINE DIOXIDE GENERATORS

LOTUS
Catalogue

LOTUS chlorine dioxide generators can be used in a wide variety of industries for the control of micro-organisms in water systems and are particularly recommended for the reduction, control and prevention of Legionella in cold and hot water systems.

LOTUS chlorine dioxide based biological control systems are reliable and safe, being designed so there is no requirement to handle ClO2 as a gas: two liquid chemicals, Hydrochloric Acid (HCl) and Sodium Chlorite (NaClO2), react together to form the chlorine dioxide required, so there is no ClO2 gas or concentrated solutions outside of the process application. An active carbon filter further prevents potential exhalations.

Thanks to EMEC online control system ERMES, you will also be able to monitor and interact with LOTUS systems from everywhere and through a simple but powerful web interface.

LOTUS AIR  I
ManualDatasheet

LOTUS AIR is a pressure-less chlorine dioxide generator useful for those applications in which several injection points are required. Chlorine dioxide is produced from diluted base chemicals: acid-chlorite process by Hydrochloric Acid (HCl 9%) and Sodium Chlorite (NaClO2 7,5%).

Chlorine dioxide produced by LOTUS AIR is stocked into a tank and then dosed proportionally to the request. A multifunction valve guarantees the safety of the process. LOTUS AIR can be equipped with a gas detection sensor.

RANGE: 10-60 g/h
MAX CAPACITY: 1440 g/day

– LOTUS AIR WITH PROBE MEASURE models are also equipped with a ClO2 probe (SVCL2/SVCL17) or an mV probe (ERH), a probe holder and a filter.

LOTUS MINI  I
ManualDatasheet

LOTUS MINI is a versatile and complete solution for all your water disinfection needs. Its elegant cover preserves the cleanliness of the inner components and their integrity. Chlorine dioxide produced by LOTUS MINI can be proportional to the circulating water flow or based on a measured setpoint.

There is no storage of chlorine dioxide therefore there is no chlorine dioxide gas or concentrated solutions outside of the process application. LOTUS MINI can be equipped with a gas detection sensor.

RANGE: 8-20 g/h
MAX CAPACITY: 480 g/day

– LOTUS MINI WITH PROBE MEASURE models are also equipped with a ClO2 probe (SVCL2/SVCL17) or an mV probe (ERH), a probe holder and a filter.

LOTUS MAXI  I
ManualDatasheet

LOTUS MAXI is a series of complete and powerful chlorine dioxide generators for superior water disinfection needs, such as in large water treatment plants.

Chlorine dioxide produced by LOTUS MAXI is set to be proportional to the circulating water flow or based on a setpoint, it is then dosed into the water flow. LOTUS MAXI can be equipped with a gas detection sensor.

RANGE: 80-1000 g/h
MAX CAPACITY: 24000 g/day

– LOTUS MAXI WITH PROBE MEASURE models are also equipped with a ClO2 probe (SVCL2/SVCL17) or an mV probe (ERH), a probe holder and a filter.

LOTUS ULTRA  I
ManualDatasheet

LOTUS ULTRA is the largest product among EMEC chlorine dioxide generators and is the best solution when there is a need for large production, such as in the largest water treatment plants.

Chlorine Dioxide is produced from concentrated base chemicals: Hydrochloric Acid (HCl 33%) and Sodium Chlorite (NaClO2 25%).

Chlorine dioxide produced by LOTUS ULTRA is set to be proportional to the circulating water flow or based on a setpoint, it is then dosed into the water flow. LOTUS ULTRA can be equipped with a gas detection sensor.

RANGE: 1000-4000 g/h
MAX CAPACITY: 96000 g/day

– LOTUS ULTRA WITH PROBE MEASURE models are equipped with a ClO2 probe (SVCL2/SVCL17) or an mV probe (ERH), a probe holder and a filter.

LOTUS EASY  I
ManualDatasheet

LOTUS EASY is the best solution for a simple but professional way to produce chlorine dioxide, thanks to an integrated All-in-One system with a controller and two metering pumps.

Chlorine dioxide produced by LOTUS EASY can be proportional to the circulating water flow. There is no storage of chlorine dioxide therefore there is no chlorine dioxide gas or concentrated solutions outside of the process application. Multifunction valves on injection points ensure the security of the reaction chamber.

RANGE: 8-80 g/h
MAX CAPACITY: 1920 g/day
